Avery Dennison
Avery Dennison DOL 1460Z Gloss Overlaminate
Avery Dennison DOL 1460Z ultra-thin super-conformable gloss cast laminate for deep channels and 3D wraps with MPI 1105. Up to 7 yr. 54" and 60" x 50 yd.
$765.18
SKU ADOL1460Z-54
2 options: $765.18 – $850.20
In stock
Orders over $10,000 are paid by bank wire or ACH only.
Choose an option
Is it right for your job?
Best for
- The most difficult 3D wraps on Avery MPI 1105
- Deep channels and compound curves
- High-gloss paint-like finish
Not for
- Flat signs where calendered is cheaper
- Floor graphics
Overview
Avery Dennison DOL 1460Z Gloss is a premium, ultra-thin, super-conformable UV-stable cast PVC overlaminate (30 micron face) with a permanent acrylic adhesive on a 50 micron transparent PET liner. Avery designed it for use with MPI 1105 SuperCast media on the most difficult 3D applications, with excellent deep recess (channel) and compound-curve performance.
Avery's DOL 1460Z data sheet lists an outdoor life of up to 7 years, a wet-paint-like high gloss finish (90% at 60°), brilliant transparency, and exceptional adhesion to solvent, UV-curable, latex and screen-printed graphics. It also gives finished graphics extra body for application without the need for application tape.
Common applications are cars and vans, corrugated and flat-sided trucks, exterior and illuminated signage, window graphics and marine vessels. Choose DOL 1460Z over DOL 1360Z when a wrap has deep channels or complex 3D shapes.
Key features
- Ultra-thin 30 micron UV-stable cast PVC, high gloss
- Excellent deep-recess and compound-curve performance with MPI 1105
- Up to 7 yr outdoor life (Avery data sheet)
- Wet-paint-like gloss, brilliant transparency
- Adheres well to solvent, UV, latex and screen prints
- PET liner for easy converting
Specifications
| Film | Cast PVC, clear, UV-stable |
|---|---|
| Thickness | 30 micron (approx. 1.2 mil) |
| Adhesive | Clear, permanent acrylic |
| Liner | 50 micron transparent PET |
| Finish | High gloss |
| Gloss 60 | 90% |
| Durability | Up to 7 yr outdoor (Avery data sheet) |
| Application surfaces | Flat, Corrugated, Compound curves, Deep recesses / channels |
| Compatible films | Avery Dennison MPI 1105 SuperCast |
| Applications | Cars and vans, Corrugated and flat-sided trucks, Exterior signage, Window graphics, Illuminated signage, Marine vessels |
| Width | 54" |
| Roll length | 50 yd |
| Sub category | Cast Laminate |
| Laminate tier | Premium (cast) |
Specifications shown for the selected option (54" x 50 yd).
Printer compatibility
Laminates are not printed. The 54" or 60" rolls cover prints from the 64" HP Latex 570. Laminate HP Latex 570 prints only after they have fully cured and cooled; latex prints come out dry, but follow the film maker's guidance before laminating.
Pairs well with
- Avery Dennison MPI 1105 SuperCast Easy Apply RS → Avery Dennison MPI 2903 Easy Apply Gloss Vinyl Film, Avery Dennison MPI 1105 SuperCast Easy Apply RS Film
Compare with
- Avery Dennison DOL 1360Z Gloss Overlaminate — DOL 1300Z gloss, 1.3 mil
- 3M Gloss Wrap Overlaminate 8428G — 3M thin gloss wrap laminate for IJ280
- ORAGUARD 293 Ultra Flexible Cast PVC Laminating Film — ORAFOL ultra-thin cast
Documents
FAQ
What is DOL 1460Z designed for?
Avery designed it for use with MPI 1105 SuperCast for the most difficult 3D applications, with excellent deep recess and compound-curve performance.
How long does DOL 1460Z last?
Avery's DOL 1460Z data sheet lists an outdoor life of up to 7 years.
DOL 1460Z or DOL 1360Z?
Both are ultra-thin gloss cast laminates for MPI 1105; choose 1460Z for the deepest channels and most complex shapes.
