General Formulations
General Formulations 231 AutoMark Overlaminate
GF 231 AutoMark 2.4 mil polymeric calendered gloss wrap laminate, up to 7 yr outdoors. Pairs with GF 230 for fleet, decals. 54"/60" x 150'.
$498.32
SKU 231-54
2 options: $498.32 – $617.44
In stock
Orders over $10,000 are paid by bank wire or ACH only.
Choose an option
Is it right for your job?
Best for
- Fleet, trailer and box-truck graphics
- GF 230 AutoMark prints
- Long-term outdoor decals
Not for
- Deep recesses and complex compound curves (use cast)
- Budget indoor work
Overview
General Formulations 231 AutoMark is a premium 2.4 mil calendered gloss UV wrap laminate (clear polymeric vinyl) with a clear permanent solvent acrylic adhesive on a 53# PE-coated kraft liner. GF lists outdoor durability up to 7 years and gloss above 70 at 60°.
GF engineered 231 for most vehicle wrap and decal applications and intends it to be paired with GF 230 AutoMark vinyl, for fleet, wrap, general signage and long-term outdoor graphics. It is applied cold, without heat. With GF 230 the combination carries an ASTM E84 Class 1 or A flammability rating.
Choose 231 when you want a polymeric wrap laminate for box trucks, trailers and decals at a lower price than cast. For deep recesses and compound curves, a cast laminate such as 3M 8518 or Avery DOL 1360Z is the safer choice.
Key features
- 2.4 mil polymeric calendered gloss laminate
- Outdoor durability up to 7 yr
- Clear permanent solvent acrylic adhesive
- Engineered for vehicle wrap and decal work
- Paired with GF 230 AutoMark vinyl
- Cold laminating
Specifications
| Film | Calendered polymeric vinyl, clear |
|---|---|
| Thickness | 2.4 mil |
| Adhesive | Clear, solvent acrylic, permanent |
| Liner | 53# PE-coated kraft |
| Finish | Gloss |
| Gloss 60 | >70 |
| Durability | Up to 7 yr outdoor |
| Application temperature | Above 40°F |
| Service temperature | -40°F to 180°F |
| Fire rating | ASTM E84 Class 1 or A (with GF 230) |
| Compatible films | GF 230 AutoMark |
| Applications | Vehicle wraps, Fleet, Decals, General signage, Outdoor (long term) |
| Width | 54" |
| Roll length | 150 ft |
| Sub category | Calendered Laminate |
| Laminate tier | Intermediate (calendered) |
Specifications shown for the selected option (54" x 150').
Printer compatibility
Laminates are not printed. The 54" or 60" rolls cover prints from the 64" HP Latex 570. Laminate HP Latex 570 prints only after they have fully cured and cooled; latex prints come out dry, but follow the film maker's guidance before laminating.
Pairs well with
- General Formulations 230 AutoMark
Compare with
- General Formulations 400 Series Overlaminate — GF calendered laminate for flat signs
- 3M Scotchcal Optically Clear Gloss Overlaminate 8518 — 3M cast gloss wrap laminate
- Avery Dennison DOL 1360Z Gloss Overlaminate — Avery ultra-thin cast gloss laminate
Documents
FAQ
How long does GF 231 last?
General Formulations lists outdoor durability up to 7 years.
Is GF 231 cast?
No. It is a premium 2.4 mil calendered polymeric vinyl engineered for most vehicle wrap and decal applications.
Which print film does it go with?
GF intends it to be paired with GF 230 AutoMark vinyl.
What roll lengths?
54" and 60" x 150 ft.
