Briteline
Briteline WrapCAST Overlaminate Film - 2 mil
Briteline WrapCAST 2 mil ultra-flexible cast overlaminate, 7 yr, gloss, matte or optically clear for perf. Pairs with WrapCAST film. 54" and 60" x 50 yd.
$616.59
SKU OLWC-GLS54
5 options: $616.59 – $715.94
In stock
Orders over $10,000 are paid by bank wire or ACH only.
Choose an option
Is it right for your job?
Best for
- Briteline WrapCAST vehicle wraps
- Value cast wrap systems
- Briteline Precision Perf (Optically Clear)
Not for
- 3M or Avery warranty systems (use their matched laminates)
Overview
Briteline WrapCAST Overlaminate is a 2 mil (50 micron) ultra-flexible cast laminate with a permanent solvent adhesive that wets out quickly for a clean image. It offers excellent protection against UV radiation to prevent yellowing and has a 7-year outdoor film life.
It is designed for vehicle graphics and long-term signage and gives graphics a wet-paint look. Briteline recommends pairing it with Briteline WrapCAST film, and specifies the Optically Clear version for window perf; Briteline's chart lists OLWC-OPT54 for its 50/50 and 70/30 Precision Perf. We stock gloss and matte (54" and 60") and Optically Clear (54"), all 50 yd.
WrapCAST is the value cast wrap system in our range. Let inkjet prints fully outgas before laminating. For 3M or Avery wrap films, use their matched laminates.
Key features
- 2 mil ultra-flexible cast overlaminate
- 7 yr outdoor film life
- UV protection to prevent yellowing
- Permanent solvent adhesive; no effect from 10 min gasoline or motor oil exposure
- Gloss, matte or Optically Clear (for window perf)
- Pairs with Briteline WrapCAST film
Specifications
| Film | Cast PVC, clear |
|---|---|
| Thickness | 2 mil |
| Adhesive | Clear, solvent-based, pressure-sensitive, permanent |
| Liner | Kraft paper |
| Finish | Gloss |
| Durability | 7 yr outdoor |
| Min application temperature | 50°F |
| Service temperature | -40°F to 175°F |
| Compatible films | Briteline WrapCAST, Briteline Precision Perf 70/30 and 50/50 (Optically Clear only) |
| Applications | Vehicle graphics, Long-term signage, Window perf (Optically Clear only) |
| Width | 54" |
| Roll length | 50 yd |
| Sub category | Cast Laminate |
| Laminate tier | Premium (cast) |
Specifications shown for the selected option (54" x 50 yd, Gloss).
Printer compatibility
Laminates are not printed. The 54" or 60" rolls cover prints from the 64" HP Latex 570. Laminate HP Latex 570 prints only after they have fully cured and cooled; latex prints come out dry, but follow the film maker's guidance before laminating.
Pairs well with
Compare with
- ORAGUARD 290 Premium Cast PVC Laminating Film — ORAFOL 2 mil cast laminate
- 3M Scotchcal Optically Clear Gloss Overlaminate 8518 — 3M cast gloss laminate
- ORAGUARD 290GF Optically Clear Laminating Film — ORAFOL optically clear for perf
FAQ
What film should WrapCAST Overlaminate be used with?
Briteline recommends pairing it with Briteline WrapCAST film.
Which finish for window perf?
Use the Optically Clear version; Briteline lists it for its Precision Perf films.
How long does it last?
Briteline lists a 7-year outdoor life for the film.
